r/lurebuilding • • Jan 02 '20

How to Make Your Own Lures: A Guide series

101 Upvotes

​

1. What kind of lures can I make?

  • Crankbaits (Lipped and Lipless), Jerkbaits (Lipped and Lipless), Swimbaits, Poppers, Stickbaits, and other topwater lures are all possible, with new lures being invented all the time! Below is an info graphic with a few of the most popular types of fishing lures, but there are many more!
These are just a few common lures that can be found in most tackle boxes, but there are dozens of other types to discover!

2. What do I need to get started making hard body lures?

  • Lure making is not as complicated as it may seem. Yes, power tools such as drills, dremels, lathes and sanding machines all help, but none are necessary. To start all you need is:
  • Wood, to carve into the body.
  • Tools (at the very least a knife to carve, a small saw, and a drill are all very helpful)
  • Sandpaper to finish the bait off smoothly
  • Terminal tackle, including hooks and split rings
  • Screw eyes or a through-wire (a single wire going through the entire bait that serves as your hook eyes and line tie.
  • Weights so your bait sinks, in the form of either split shot, glued into the body, or lead, poured into a cavity.
  • glue/sealant, epoxy, and paint
  • OPTIONAL: Lip (for crankbaits) Rattles, details such as foil, and power tools, and an airbrush for more smooth

3. What do I need to get started making soft plastics?

  • A mold, which can be bought, or made from silicon.
  • Plastic resin (plastisol)
  • Dye to give color to the lure
  • OPTIONAL: Glitter, multiple colors for a more detailed bait

4. What wood should I use?

  • Popular lure making timbers include balsa, basswood, cedar, cypress knees, jelutong, beech and some types of pine. But there are thousands of other options. Look for something easy to carve, lightweight and resistant to denting. Itโ€™s easier to get all your components aligned properly if you start with straight, square blanks.

5. What paints should I use?

  • For brushing on paint, a wide variety of artist acrylics and poster paints will work. Just make sure the paint and clear coat will not interfere.
  • For airbrushing, water-based acrylics are the favorite, due to their ability to spray evenly and produce a good coat while remaining non-toxic, and non-flammable.

6. How do I seal my wood lure?

  • Wood is like a sponge, it soaks up water. Once in, water works its way through the wood by capillary action until the wood is waterlogged. This kills action, weakens glue and is the most common cause of paint failure.
  • Super Glue can be used, where the glue is applied over the entire body, left to soak into the wood, and then the bait is sanded smooth.
  • Epoxies are two part synthetic resins that cure hard when mixed. There are some that are designed for penetrating and hardening wood. One example is Envirotex Lite (aka โ€œEtexโ€). Etex is also great for clear coating painted lure bodies and makes a very strong adhesive.

7. Where can I buy lure parts?

8. What epoxy should I use?

  • Some use prefer to clear coat them with a two part epoxy. Others prefer to use a two pack automotive polyurethane over airbrush acrylics. And still others dip their lures in moisture cure polyurethane.

Below are some some more sources for learning how to build lures, additionally, guides from some of this subs best lure mentors are going to be rolling out very shortly.

​

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

​

This stickied post will be used to compile all guides made by our "Lure Mentors." Below are links to each guide, complete with pictures and detailed descriptions for each step. If you would like to become a Lure Mentor, and create guides for this sub Please PM me ( u/jspencer501 ) for more details, you get a cool flair!

Guide 1 - Lipless Crankbait By u/zingerbobingerGuide 2 - Lure made of Paper By u/SolarBaits

More guides will be coming out in the weeks to come! please let me know any comments or concerns.


r/lurebuilding • • 10h ago

Other Blender lure designer

Enable HLS to view with audio, or disable this notification

6 Upvotes

Work in progress, a lure designer add on for blender. It allows exporting stl for 3d printing and unwrapping into a flat pattern for a 4th axis wood carving cnc hack.


r/lurebuilding • • 18h ago

Swimbait A family of rodents.

Thumbnail
gallery
19 Upvotes

r/lurebuilding • • 16h ago

Fly Inline Streamer-Spinner? Overcomplicated bucktail? Advice welcome.

Thumbnail
gallery
5 Upvotes

Hello, new here!

After fly fishing for many years, I have moved somewhere that fly-fishing in moving waters is not so easily accessible. After fishing spinning gear all summer (spinners, jigs, chatterbaits, etc.) for perch and pike; I thought, 'why not have the best of both worlds?'.

So here is my first draft.

My idea is that I could have different weighted spinner sections that I could change according to depth or current speed, while at the same time being able to change the fly whenever I want also.

I am very open to suggestions about how I could improve this, adding a blade or a swivel somewhere maybe?

Looking forward to everyones input and thanks for your time!

Tightlines!


r/lurebuilding • • 1d ago

Jerkbait Brown trout candy clear colour difference.

Enable HLS to view with audio, or disable this notification

55 Upvotes

Layering candy clear colours over a silver chrome base creates some nice depth to the finish. My original brown trout pattern is the one with hooks and bib attached.


r/lurebuilding • • 1d ago

Stickbait Topwater trout walker

Thumbnail
gallery
45 Upvotes

Check out my Instagram for more details and other builds ๐Ÿ‘
https://www.instagram.com/mo_mo_lures?dlrf=YWhkenhlYXFmYW5k&utm_source=qr


r/lurebuilding • • 1d ago

Lipless Crankbait Modified Rattletrap

Thumbnail
gallery
11 Upvotes

So I had an ideal last night๐Ÿ˜Ž


r/lurebuilding • • 2d ago

Swimbait Showing my base painting process

Enable HLS to view with audio, or disable this notification

238 Upvotes

r/lurebuilding • • 2d ago

Decorative Probably nicest lure eyes ive made to date.

Enable HLS to view with audio, or disable this notification

26 Upvotes

r/lurebuilding • • 2d ago

Popper My first ever handmade lure!

Post image
18 Upvotes

I saw marling baits making a tiny popper, and thought i wanna do that too, so i got to work and this is what came out. i used some old wood from the carage and nail polish for clear coat. let me know what you think and if you have tips please tell me.


r/lurebuilding • • 2d ago

Question How do you get a good UV clear coat?

3 Upvotes

I've tried alumi uv and the cheap Chinese stuff, can't seem to get a good coat with either. The Alumi beads up and the Chinese stuff contracts as it cures uncovering a few spots. Any advice would be appreciated.


r/lurebuilding • • 2d ago

Soft plastic Mold making 3d printer

2 Upvotes

I am interested in making molds via a 3d printer and have an open mold idea of a swimbaits and wanted to know if anyone had suggestions on the right plastic to use for the mold due to the plastisol heat. Asking for any recommendations anyone has.

Also thought about the silicone mold route but not sure how that all works, would have to do a lot of research on it.


r/lurebuilding • • 2d ago

Question Sand clear blanks before painting?

0 Upvotes

Should I sand a clear lure blank before painting it? I'm far from good at this, so I'm just going to paint a knockoff Megabass Megadog bone white with a spray can, glue on some eyes, and follow with clear epoxy.


r/lurebuilding • • 3d ago

Swimbait Experimenting with adding color to bucktail hair. Attempt 1 - Permanent Marker.

Thumbnail
gallery
4 Upvotes

Seems to work ok. Gonna try Createx next.


r/lurebuilding • • 3d ago

Question Is it a time thing?

Thumbnail
2 Upvotes

r/lurebuilding • • 4d ago

Swimbait Triple Injectors

Thumbnail
gallery
49 Upvotes

Triple laminations are very difficult to produce but the results are like no other. Attempted to match my Blue Chartreuse Rapala Jerk Bait. What do you think?


r/lurebuilding • • 4d ago

Decorative Custom eyes

Enable HLS to view with audio, or disable this notification

32 Upvotes

r/lurebuilding • • 5d ago

Lipless Crankbait Sunrise ๐ŸŒ„ and Sunset ๐ŸŒ†

Thumbnail
gallery
60 Upvotes

r/lurebuilding • • 5d ago

Successful Catch First fish on my first lure iโ€™ve made ever :). i threw my other lure thatโ€™s white black and red but no dice lol.

Thumbnail
gallery
84 Upvotes

r/lurebuilding • • 5d ago

Glidebait Hand painted wake bait because my airbrush broke

Thumbnail
gallery
21 Upvotes

What do you guys think of my first wake bait I think I did an alright job kinda sloppy but hey it looks good to me and the pink I chose pops like crazy js look at that tail just needs a clear coat ๐Ÿ˜ฎโ€๐Ÿ’จ๐Ÿ˜ฎโ€๐Ÿ’จ


r/lurebuilding • • 6d ago

Lipless Crankbait Pair of lipless crankbaits I made today

Enable HLS to view with audio, or disable this notification

74 Upvotes

Two lipless cranks I cut, carved and painted today. Been rained out from work and had a bit of time up my sleeve. Finished them both in about 6 hours from a block of timber to this! Can't wait to see the action.


r/lurebuilding • • 6d ago

Spoon Epoxy Putty for Spoons

Thumbnail
gallery
17 Upvotes

changed the design to have a stainless steel wire running through the center, and the aluminum wire frame just to stop it chipping on rocks. tested them today and they work pretty well. They spin, they wobble, they do a little dance. They're just about the perfect weight, so I think I'll be making more of these and trying out something else next.


r/lurebuilding • • 8d ago

Soft plastic Green Pumpkin #handmadelure #bassfishing #luremaking

Thumbnail
youtube.com
3 Upvotes

r/lurebuilding • • 8d ago

Glidebait First brush tail

Post image
64 Upvotes

r/lurebuilding • • 8d ago

Glidebait Added the articulation

Enable HLS to view with audio, or disable this notification

17 Upvotes
